China Manufacturer for Handle Operated Butterfly Valve - rubber sealing grooved end signal butterfly valve – Jinbin Valve Detail:

rubber sealing grooved end signal butterfly valve


Size: DN50-200

Design standard: API 609, BS EN 593.

Face-to-Face dimension: API 609, BS EN558.

Flange Drilling: ANSI B 16.1, BS EN 1092-2 PN 10 / PN 16.

Test: API 598.

Manual wafer butterfly valve(Lever type)

Working Pressure

10 bar / 16 bar/150lb

Testing Pressure

Shell: 1.5 times rated pressure,

Seat: 1.1 times rated pressure.

Working Temperature

-10°C to 120°C (EPDM)

-10°C to 150°C (PTFE)

Suitable Media

Water, Oil and gas.

Manual wafer butterfly valve(Lever type)

Parts

Materials

Body

cast iron

Disc

Stainless steel

Seat

EPDM / NBR / VITON / PTFE

Stem

Stainless steel

Bushing

PTFE

“O” ring

PTFE

Pin

Stainless steel

Key

Stainless steel

Manual wafer butterfly valve(Lever type)

The butterfly valve is mainly used in the pipe in drainage, fire, air conditioner, gas, petroleum, chemicals, water treatment and so on.
