Special Price for Actuated Butterfly Valve - butterfly type tilting disc flange check valve with oil cylinder – Jinbin Valve Detail:

Tilting disc flange Check Valve with counterweight


For BS 4504 BS EN1092-2 PN10 / PN16/ PN25 flange mounting.

Face-to-Face dimension conforms to ISO 5752 / BS EN558 serial 14.

Epoxy fusion coating.

Tilting disc flange check valve with oil cylinder

Working Pressure

PN10 / PN16 / PN25

Testing Pressure

Shell: 1.5 times rated pressure,

Seat: 1.1 times rated pressure.

Working Temperature

-10°C to 80°C (NBR)

-10°C to 120°C (EPDM)

Suitable Media

Water, sewage etc.

Shell and seal tests for each valve is done and recorded before package to make sure the product quality. The test media is water in room conditions.

Tilting disc flange check valve with oil cylinder

Tilting disc flange check valve with oil cylinder

Part

Material

Body

Ductile Iron/Carbon steel

Disc

Ductile Iron / Stainless Steel

Spring

Stainless Steel

Shaft

Stainless Steel

Seat Ring

NBR / EPDM

Cylinder/Piston

Stainless steel

If need the drawing details, please feel free to contact.

Tilting disc flange check valve with oil cylinder

This check valve is used for preventing the back-going of medium in pipelines and equipments, and the pressure of medium will bring the result of opening and closing automatically.When the medium is back-going, valve disc will automaticaly closed to avoid accidents.

Tilting disc flange check valve with oil cylinder

Tilting disc flange check valve with oil cylinder
