Float ball steam trap

Product introduction:

The structure of the free floating ball steam trap is simple. There is only one stainless steel hollow ball which is finely researched and grinded inside. It is not only a float but also an opening and closing part. It has no vulnerable parts and has a long service life. When the device is just started, there is air and low-temperature condensate in the pipeline. The manual exhaust valve can quickly remove the non condensable gas, and the steam trap starts to enter the working state. The low-temperature condensate water flows into the drain valve, the condensate level rises, and the floating ball rises to open the valve. The device quickly raises the temperature, and before the temperature in the pipeline rises to the saturation temperature, the automatic air valve has been closed; when the device enters into normal operation condition, the condensate decreases and the liquid level drops, and the floating ball adjusts the valve orifice flow with the rise and fall of the liquid level; when the condensate stops flowing into the valve, the floating ball approaches the valve seat with the flow direction of the medium and closes the valve. The valve seat of the free floating ball steam trap is always below the liquid level to form a water seal without steam leakage.

Size: DN15-DN150

Standard: ASME, EN, BS
