Short Description:

Manual resilient seat flanged butterfly valve Size: 2”-48” / 40mm – 1200 mm Design standard: API 609, BS EN 593. Face-to-Face dimension: API 609, BS 5155, ISO 5752. Flange Drilling: ANSI B 16.1, BS4504, DIN PN 10 / PN 16, JIS 5K, 10K, 16K. Test: API 598. Working Pressure PN10 / PN16 Testing Pressure Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. Working Temperature -10°C to 80°C (NBR) -10°C to 120°C (EPDM) Suitable Media Water, Oil and gas. ...


Email WhatsApp

Product Detail

Product Tags

Related Video

Feedback (2)

We rely upon strategic thinking, constant modernisation in all segments, technological advances and of course upon our employees that directly participate inside our success for 10 Inch Strainer , Butterfly Valve For Sea Water , Ball Valve Ss304 , We believe that in good quality more than quantity. Before export of the hair there is strict top quality control check during treatment as per international good quality standards.
Factory Supply Rubber Disc Check Valve - Manual resilient seat flanged butterfly valve – Jinbin Valve Detail:

Manual resilient seat flanged butterfly valve

Size: 2”-48” / 40mm – 1200 mm

Design standard: API 609, BS EN 593.

Face-to-Face dimension: API 609, BS 5155, ISO 5752.

Flange Drilling: ANSI B 16.1, BS4504, DIN PN 10 / PN 16, JIS 5K, 10K, 16K.

Test: API 598.


Working Pressure

PN10 / PN16

Testing Pressure

Shell: 1.5 times rated pressure,

Seat: 1.1 times rated pressure.

Working Temperature

-10°C to 80°C (NBR)

-10°C to 120°C (EPDM)

Suitable Media

Water, Oil and gas.


Parts

Materials

Body

Cast iron, ductile iron, carbon steel, stainless steel

Disc

Nickel ductile iron / Al bronze / Stainless steel

Seat

EPDM / NBR / VITON / PTFE

Stem

Stainless steel / Carbon steel

Bushing

PTFE

“O” ring

PTFE

Worm gearbox

Cast iron / Ductile iron

The product is used for throttling or shutting off the flow of corrosive or non corrosive gased, liquids and semi liquid. It can be installed in any selected position in pipelines in the industries of petroleum processing, chemicals, food, medicine, textile, paper making, hydroelectricity engineering, building, water supply and sewage, metallurgy, energy engineering as well as light industry.

1 2

Product detail pictures:

Factory Supply Rubber Disc Check Valve - Manual resilient seat flanged butterfly valve – Jinbin Valve detail pictures

Factory Supply Rubber Disc Check Valve - Manual resilient seat flanged butterfly valve – Jinbin Valve detail pictures

Factory Supply Rubber Disc Check Valve - Manual resilient seat flanged butterfly valve – Jinbin Valve detail pictures

Related Product Guide:
Specialized Epic 2018: Farewell FSR Hello Single Pivot | Grooved Butterfly Valve
Glenmore Water Reservoir renovations on ballot | News | Grooved Butterfly Valve
Our pursuit and enterprise aim would be to "Always fulfill our buyer requirements". We carry on to acquire and layout excellent quality items for the two our old and new clients and realize a win-win prospect for our shoppers in addition as us for Factory Supply Rubber Disc Check Valve - Manual resilient seat flanged butterfly valve – Jinbin Valve , The product will supply to all over the world, such as: Bangladesh, Seattle, Finland, Our focus on product quality, innovation, technology and customer service has made us one of undisputed leaders worldwide in the field. Bearing the concept of "Quality First, Customer Paramount, Sincerity and Innovation" in our mind, We have achieved great progress in the past years. Clients are welcomed to buy our standard products, or send us requests. You will be impressed by our quality and price. Please contact us now!

    • The factory workers have a good team spirit, so we received high quality products fast, in addition, the price is also appropriate, this is a very good and reliable Chinese manufacturers.
    5 Stars By Elaine from Brazil - 2018.06.03 10:17
    We always believe that the details decides the company's product quality, in this respect, the company conform our requirements and the goods are meet our expectations.
    5 Stars By Nelly from California - 2017.12.31 14:53
