Quality Inspection for Ss Ball Valve - Electric blind valve Goggle valve – Jinbin Valve Detail:

Electric blind valve Goggle Valve

Electric blind valve Goggle valve

Goggle valve contains body, disc, stem, left and right nut, srew, seat, equipment etc.

1. This kind of valve is made of right and left body, circulator sector gate, pin nut etc.

2. Rubber sealing is embeded in valve body and has the better seal. It is easy to change and has long term service.

Pressure: 0.01-2.5 Mpa

Size: D200-DN2000

Media: Metallurgy, chemical, power etc.

Electric blind valve Goggle valve

Norminal Pressure Mpa 0.05 0.10 0.15 0.25
Sealing Test 0.055 0.11 0.165 0.275
Sheel Test 0.075 0.15 0.225 0.375
Air Source Compressed Air 0.4-0.6 Mpa, Oil Pressure 6.3Mpa, 3way 380V
Working Temperature -20-100oC / -20-200 oC / -20-300 oC
Suitable Media Coal gas etc toxic, poisonous flammable gas
Closing time (S) <60

Electric blind valve Goggle valve

Part Body/Disc Lead screw Nut Compensator Sealing
Material Carbon steel Alloy steel Manganin Alloy Stainless steel Viton/NBR/Silicone rubber

Electric blind valve Goggle valve

Electric blind valve Goggle valveElectric blind valve Goggle valve

Electric blind valve Goggle valve

It is widely used in the pipe system of metallurgical,chemical,electric power and other industries for the purpose of  cutting off or connecting.
