Rigid dismantling Joint

Short Description:

Rigid dismantling Joint Size: 65mm –1200 mm Flange Drilling: ANSI B 16.1, BS4504, ISO 7005-2, BS EN1092-2 PN 10 / PN 16. Test: API 598. Epoxy fusion coating. Working Pressure 10 bar / 16 bar Testing Pressure Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. Working Temperature -10°C to 80°C (NBR) -10°C to 120°C (EPDM) Suitable Media Water, Oil and gas. Parts Materials Body Ductile iron / Carbon steel   Seal EPDM NOTE: PLEASE...


Product Detail

Product Tags

Rigid dismantling Joint

Rigid dismantling Joint

Size: 65mm –1200 mm

Flange Drilling: ANSI B 16.1, BS4504, ISO 7005-2, BS EN1092-2 PN 10 / PN 16.

Test: API 598.

Epoxy fusion coating.

Rigid dismantling Joint

Working Pressure

10 bar / 16 bar

Testing Pressure

Shell: 1.5 times rated pressure,

Seat: 1.1 times rated pressure.

Working Temperature

-10°C to 80°C (NBR)

-10°C to 120°C (EPDM)

Suitable Media

Water, Oil and gas.

Rigid dismantling Joint

Parts

Materials

Body

Ductile iron / Carbon steel

  Seal

EPDM

Rigid dismantling Joint

Rigid dismantling Joint

Rigid dismantling Joint

NOTE: PLEASE CONTACT FOR MORE INFORMATION.

Rigid dismantling Joint

It is used  for all flanged piping materials line.

The dismantling joint enables easy installation and dismantling of isolating valves , non return valves , flow metering equipment , pumps etc.
