China Wafer type signal disc swing Check Valve Manufacturer and Supplier

Wafer type signal disc swing Check Valve

Short Description:

Single disc wafer Check Valve For BS 4504 BS EN1092-2 PN16/ PN25 flange mounting. Face-to-Face dimension conforms to ISO 5752 / BS EN558. Working Pressure PN16 / PN25 Testing Pressure Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. Working Temperature -10°C to 80°C (NBR) -10°C to 120°C (EPDM) Suitable Media Water, Oil and gas. Part Material Body WCB / CF8 /CF8M / CF3M Disc WCB / CF8 /CF8M / CF3M l Shaft Stainless Steel ...

FOB Price: US $10 - 9,999 / Piece

Min.Order Quantity: 1 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Send email to us Download as PDF

Product Detail

Product Tags

Single disc wafer Check Valve

Wafer type signal disc swing Check Valve

For BS 4504 BS EN1092-2 PN16/ PN25 flange mounting.

Face-to-Face dimension conforms to ISO 5752 / BS EN558.

Wafer type signal disc swing Check Valve

Working Pressure	PN16 / PN25
Testing Pressure	Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure.
Working Temperature	-10°C to 80°C (NBR) -10°C to 120°C (EPDM)
Suitable Media	Water, Oil and gas.

Wafer type signal disc swing Check Valve

Part	Material
Body	WCB / CF8 /CF8M / CF3M
Disc	WCB / CF8 /CF8M / CF3M l
Shaft	Stainless Steel
Seat Ring	EPDM

Wafer type signal disc swing Check Valve

This check valve is used for preventing the back-going of medium in pipelines and equipments, and the pressure of medium will bring the result of opening and closing automatically.When the medium is back-going, valve disc will automaticaly closed to avoid accidents.
