hand wheel operation PN16 flange connection SS304 knife gate valve
hand wheel operation PN16 flange connection SS304 knife gate valve
The movement direction of the knife gate valve is perpendicular to the fluid direction, and the medium is cut off by the gate. In order to achieve high sealing performance, the O-ring sealing seat can be selected to achieve bidirectional sealing.
The knife gate valve has small installation space, not easy to accumulate debris and etc.
The knife gate valve should generally be installed vertically in pipeline.
This knife gate valve is used in chemical industry, coal, sugar, sewage, paper making andother fields widely. It is an ideal sealed valve, especially suitable for adjusting and cut off the pipe in paper industry
| Connection pressure rating | PN16 |
| Working pressure | 10 bar |
| Test pressure |
Shell: 1.5 times rated pressure, Seat: 1.1 times rated pressure. |
| Working temperature |
-10°C to 80°C (NBR) -10°C to 120°C (EPDM) |
| Suitable fluid | Slurry, mud, waste water etc. |
| No. | Part | Material |
| 1 | Body | stainless steel |
| 2 | Bonnet | stainless steel |
| 3 | Gate | 304 |
| 4 | Sealing | EPDM |
| 5 | Shaft | 420 |
