Zero leakage pneumatic stainless steel high temperature butterfly valve

Pneumatic triple offset butterfly valve

Pneumatic zero leakage stainless steel high temperature butterfly valve adopts three-dimensional eccentric structure, the butterfly plate is hard and soft laminated metal sheet, with the dual advantages of hard metal seal and elastic seal. It has two-way sealing function and is not limited by the flow direction of the medium, and is not affected by the space position. It can be installed in any direction.

Pneumatic triple offset butterfly valve

Working Pressure

PN2.5/6/10 / PN16

Testing Pressure

Shell: 1.5 times rated pressure,

Seat: 1.1 times rated pressure.

Working Temperature

-30°C to 400°C

Suitable Media

Water, Oil and gas.

Pneumatic triple offset butterfly valve

Parts

Materials

Body

WCB, carbon steel welding, stainless steel

Disc

Nickel ductile iron / Al bronze / Stainless steel

Seat

Stianless steel

Stem

Stainless steel / Carbon steel

Bushing

Grahpit



actuator

pneumatic

Pneumatic triple offset butterfly valve

The Pneumatic zero leakage stainless steel high temperature butterfly valve is widely used in metallurgy, electric power, petroleum, chemical and other industrial pipes with medium temperature (< 425) to regulate the flow rate and cut off the fluid.
